front.common.in-stock VERTICAL LATHE VSC 1250LC
Vertical lathe with the designation VSC 1250LC. Siemens control system.
Selected equipment: full cover, 12-position magazine outside the working area, cooling through the tool center, linear measurement in the X and Z axes, sliding axis guidance, rotary tool drive, two-stage gearbox of the main spindle and the spindle of rotary tools.
Delivery date: the machine will be exhibited at the EMO and MSV 2025 engineering fair, then it will be available.
Price: with regard to possible additional equipment and services from 7,500,000 CZK.
Payment terms: individual, a minimum deposit is required.
Warranty: 24 months with the possibility of extension, service start within 24 hours after reporting.
ControllerSinumerik 828D
Magazine possitions12
Tool clampingBT50
Workpiece clampingHydraulické sklíčidlo/ruční upínací deska
Table (chuck) diameter600 | 800 | 1000 mm
Max. swing diameter1200 mm
Max. workpiece height900 mm
Max. workpiece weight4000 kg
Max. main spindle RPM600 rpm
Machine weight19000 kg
Main power16/24 kW (14114 Nm)
